Channel Width: 4.8" interior - 6 " total
Material: Polymer Concrete
Edge Protection: Integrated Galvanized Edge
Channel Width: 4.8" interior - 6 " total
Material: Polymer Concrete
Edge Protection: Integrated Stainless Steel Edge
Grate Width: 4.8" interior
Material: Galvanized, Ductile, Stainless
Use with: K100 Series, KS 100 Series
Channel Width: 8" interior - 9.5" total
Material: Polymer Concrete
Edge Protection: Integrated Galvanized Edge
Channel Width: 8" interior - 9.5" total
Material: Polymer Concrete
Edge Protection: Integrated Stainless Edge
Grate Width: 9 3/8" Wide
Material: Galvanized, Ductile, Stainless
Use with: K200 Series, KS200 Series
Channel Width: 12" interior - 14 " total
Material: Polymer Concrete
Edge Protection: Galvanized Edge
Channel Width: 12" interior - 14 " total
Material: Polymer Concrete
Edge Protection: Stainless Steel Edge
Grate Width: 13 5/16" Wide
Material: Galvanized, Ductile, Stainless
Use with: K300 Series, KS300 Series
Channel Width: 4.8" interior - 6 " total
Material: Polymer Concrete
Edge Protection: Integrated Ductile Iron Edge
Channel Width: 8" interior - 9.5 " total
Material: Polymer Concrete
Edge Protection: Integrated Ductile Iron Edge
Channel Width: 12" interior - 14 " total
Material: Polymer Concrete
Edge Protection: Integrated Ductile Iron Edge
Channel Width: 4"
Material: Polyester Polymer Concrete
Edge Protection: Non Metallic, Ductile, Galvanized and Stainless Steel
Channel Width: 8"
Material: Polyester Polymer Concrete
Edge Protection: Ductile, Galvanized and Stainless Steel
Channel Width: 12"
Material: Polyester Polymer Concrete
Edge Protection: Ductile, Galvanized and Stainless Steel
Channel Width: 4.0" interior - 5.91" total
Material: Polyester Polymer Concrete
Edge Protection: None
Channel Width: 2" interior - 3.15" total
Material: Polymer Concrete
Edge Protection: Integrated Galvanized or Stainless Edge
Channel Width: 4.8" interior - 6" total
Material: Polyester Polymer Concrete
Edge Protection: Galvanized and Stainless Steel
Channel Width: 8" interior - 9.5" total
Material: Polyester Polymer Concrete
Edge Protection: Galvanized and Stainless Steel
Channel Width: 5" or 8"
Material: Stainless Steel
ACO Hygienic Floor Drains and Linear Drains
Channel Width: 4.8" interior - 6 " total
Material: Polymer Concrete
Edge Protection: Integrated Galvanized Edge
Channel Width: 8" interior - 10.5 " total
Material: Fiberglass
Edge Protection: Integrated Galvanized Edge
ACO Drain is the market leading modular trench drain system and is ideal for commercial applications varying from gas stations to airports.
ACO Drain systems consist of factory manufactured channel units made from either corrosion resistant polymer concrete or fiberglass, together with grates from a variety of materials for all loading applications. ACO Drain systems are available in 4”, 8” and 12” internal widths, and all systems are available with a built-in slope.
Most Popular ACO Trench Drain Series
The world’s most widely used modular trench drain is an interconnecting, general purpose 4” internal width drain system for both internal or external use. The system features an aesthetic, integrally cast-in, steel wearing edge. A wide range of grates in different styles are secured into the channel unit by the boltless locking “QuickLok” system.
An extra heavy duty trench drain system available in 4” and 12” internal widths. Each channel unit has a cast-in, ductile iron, wearing edge rail which provides support for the 200,000 lb (90 ton) load bearing grates. Grates are held captive by the unique “PowerLok” boltless locking system.
A lightweight 3.75 ” and 8” internal width system manufactured from corrosion resistant fiberglass. Each channel has a choice of steel grate supporting frames which are quick fixed to the channel units by means of push studs. A variety of grates are available for both sizes.
ACO Pictures
ACO Specifications
Specs coming soon! Contact us for Spec Sheets.
