Overview

Key advantages of TPC700 Series Heavy Duty Trench Drain:

• Hard wheel traffic such as forklifts can cause unprotected drain edges to deteriorate. The heavy duty
•  frame rails in the Polycast 700 series kits form a mechanical bond into the surrounding concrete.
• Designed to withstand long term abuse of traffic, snow plows and forklifts.
• Edge protection is recommended for any application of Load Class D or greater.

• The precast trench sections and grates are made up of 2' and 4' lengths.

• Certain 4' and all 2' channels have 4" bottom cutouts for pipe connections.
• The Polycast 700 series channels are available in Polyester or Vinyl Ester Polymer Concrete.
• The polyester as displayed here is for most drainage applications.
• Vinyl Ester Polymer Concrete is used for high corrosive and high temperatures applications,
  contact us for a quote on Vinyl Ester Polymer Concrete Applications
• To View the Polycast 600 Series Polymer Kits WITHOUT the frames Click Here

Fall Options

No Fall - Flat

The straight channel section is used where no fall is required or where natural fall suffices.  In general, installation of no fall trench drain is easier and is used in the majority of applications.

Linear Fall - Presloped

The integrated Linear fall with a constant gradient of .05% ensures a positive discharge. This presloped trench drain is used in specialty situations or where engineering specification require.

  Contact Us today.

TPC700 - POLYCAST 700 Frame and Grate Specification

TPC 500 / 600 700 - POLYCAST 500 / 600 / 700 Grate Specifications
